Another Dive into Transaction Log File Forensics

,

The Stawamus Chief, Squamish B.C.



Over the past three years since I first took a look at the

insides of a Transaction Log file, I have noticed some more great products to

enable forensics such as ApexSQL ( which makes the job simple), Lumigent Log Explorer, and other Free tools mentioned below, as

well as real world scenario that describes every step BlackHat.com

would perform in the case of the deepest dive.

Why do you care, as a DBA, or a Developer for that matter,

about what is happening in the Transaction Log? The raison d’être of a transaction log file is to write all the

necessary information we need to recuperate any and all activity happening

against the database, hence the interest.

Every SQL Server database must have at least one log file. Here are a

few ways to take a brief look what is inside the log file itself:

SELECT * FROM  ::fn_dblog(DEFAULT,

DEFAULT) AS l  -- more examples, and

details, below

dbcc

log(<DatabaseName>, 3)
-- 0 for minimum info, 1 for

more, 2 for detailed, 3 full, 4 full+hex

Perhaps you are on auditing project, and your requirement is

to be able read the active log files, as well as those that were archived.  The archived logs gave us the option, with

the help of third party tools (or thanks to in part the query above), to effectively

interrogate the log file as if it were one mega table. The way that Lumigent Log Explorer's documentation describes it: 'to

assist you in solving or recovering from problems that may occur in a typical

database system' - gets the heart of what could be a potential point-in-time

restore.  Nota Bene: Please use Full recovery model

if this is your requirement or if you are in doubt (thankfully it's a database

model default setting) here are the many reasons why.

And according to MVP Siddhart Mehta, another free tool is available which

can read and display contents of transaction log files - Internals Viewer for

SQL Server (IV). The three main components are: Allocation Map, Page Viewer,

and Transaction Log Viewer. IV integrates with SSMS and works for both SQL

Server 2005 and 2008. The tool is limited, so expect to pay for tools when full

functionality is required.

My view is that you may end up with a mystery transaction at

one point that no logic can explain, and thus your database integrity is in

question - not a place where any DBA wants to be naturally. Empowering yourself

to dig into the log file and resolve these types of mysteries is the main point

of this post, because you will be able to find out what the values were

before/after a change to the database, and who/what application has committed

the change, whereas before one typically disregards anomalies for lack of

forensic tools and time.  This gives us

motivation to ensure that log files are archived, since we're following

Erasmus' Adages proverb to 'leave no stone unturned,' with respect to resolving

such mysteries.

Given that you can query the log file (you will see

transactions as BEGIN_XACT , COMMIT_XACT), it is even therefore

possible to raise alerts for undesirable activity, e.g. someone executing data

definition language in production. Combined with Database Mail and SQL Server

Agent this can be automated

too, or in the case of Lumigent Log Explorer, one

can configure an alert for each DDL/DML command, which is perhaps useful - to

filter out problems in development.  The

approach of monitoring objects during manipulation or creation will allow you to

take control of an environment progressively and proactively.

Here are a few of the prominent columns you see in the

Transaction Log itself (full

list here – Appendix B):

    ABORT_XACT Indicates that a transaction was aborted and rolled back.

    BEGIN_CKPT A checkpoint has begun.

    BEGIN_XACT Indicates the start of a transaction.

    BUF_WRITE

Writing to Buffer.

    COMMIT_XACT Indicates

that a transaction has committed.

    CREATE_INDEX

Creating an index.

    DELETE_ROWS Rows

were deleted from a table.

    DELETE_SPLIT A page split has occurred. Rows have moved physically.

    DELTA_SYSIND  SYSINDEXES

table has been modified.

    DROP_INDEX

Dropping an index.

    END_CKPT

Checkpoint has finished.

    EXPUNGE_ROWS row

physically expunged from a page, now free for new rows.

    FILE_HDR_MODIF  SQL Server has

grown a database file.

    FORGET_XACT Shows

that a 2-phase commit transaction was rolled back.

    FORMAT_PAGE  Write a header

of a newly allocated database page.

    INSERT_ROWS  Insert a row

into a user or system table.

    MARK_DDL Data

Definition Language change - table schema was modified.

    MARK_SAVEPOINT

designate that an application has issued a 'SAVE TRANSACTION' command.

    MODIFY_COLUMNS  Designates

that a row was modified as the result of an Update command.

    MODIFY_HEADER  A new data

page created and has initialized the header of that page.

    MODIFY_ROW  Row modification

as a result of an Update command.

    PREP_XACT

Transaction is in a 2-phase commit protocol.

    SET_BITS

Designates that the DBMS modified space allocation bits as the result of

allocating a new extent.

    SET_FREE_SPACE  Designates that

a previously allocated extent has been returned to the free pool.

    SET_MASK_BITS

    SORT_BEGIN A sort begins with index creation. - SORT_END end of the

sorting while creating an index.

    SORT_EXTENT

Sorting extents as part of building an index.

    UNDO_DELETE_SPLIT

The page split process has been dumped.

    XACT_CKPT during

the Checkpoint, open transactions were detected.

Special thanks to Aliaksei Yauseichyk for his contributions to this post, and for being an enthusiastic new colleague!
